| Case/Package | SOP |
| China RoHS | Compliant |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fall Time | 30ns |
| Frequency | 400kHz |
| Height - Seated (Max) | 1.75mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 1980-01-04 |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 125°C |
| Max Output Current | 650mA |
| Max Power Dissipation | 750mW |
| Max Supply Current | 320µA |
| Max Supply Voltage | 17V |
| Min Operating Temperature | -45°C |
| Min Supply Voltage | 9V |
| Mount | Surface Mount |
| Nominal Supply Current | 220mA |
| Number of Circuits | 1 |
| Number of Drivers | 2 |
| Number of Outputs | 2 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 15V |
| Power Dissipation | 750mW |
| Propagation Delay | 110ns |
| Radiation Hardening | No |
| REACH SVHC | No |
| Rise Time | 50ns |
| RoHS | Compliant |
| Terminal Pitch | 1.27mm |
| Turn-On Delay Time | 110ns |
| Width | 3.9mm |
STMicroelectronics
|
Production
|
STMicroelectronics
|
Production
|
STMicroelectronics
|
Obsolete
|
STMicroelectronics
|
Obsolete
|
STMicroelectronics
|
Obsolete
|
