| Breakdown Voltage | 2.8V |
| Capacitance | 2.5pF |
| Case/Package | SOIC |
| China RoHS | Compliant |
| Clamping Voltage | 15V |
| Composition | Zener |
| Country of Origin | Malaysia |
| Depth | 4mm |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Dual |
| Height | 1.75mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2009-09-01 |
| Lead Free | Lead Free |
| Leakage Current | 200nA |
| Length | 5mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 600W |
| Max Repetitive Reverse Voltage (Vrrm) | 2.8V |
| Max Reverse Leakage Current | 200nA |
| Max Surge Current | 30A |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 4 |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Packaging | Tape and Reel |
| Peak Pulse Current | 12A |
| Peak Pulse Power | 600W |
| Peak Reverse Current | 200nA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 2.8V |
| RoHS | Compliant |
| Schedule B | 8536300000|8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Width | 4mm |
| Working Voltage | 2.8V |
