| Breakdown Voltage | 140V |
| Capacitance | 65pF |
| China RoHS | Non-Compliant |
| Clamping Voltage | 190V |
| Direction | Bidirectional |
| Element Configuration | Single |
| Height | 2.45mm |
| Hold Current | 150mA |
| Lead Free | Lead Free |
| Leakage Current | 2µA |
| Length | 4.6mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 150°C |
| Max Repetitive Reverse Voltage (Vrrm) | 140V |
| Max Reverse Leakage Current | 2µA |
| Max Surge Current | 100A |
| Min Breakdown Voltage | 140V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 126V |
| Peak Pulse Current | 100A |
| Polarity | Bidirectional |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 126V |
| RoHS | Compliant |
| Schedule B | 8541300080 |
| Termination | SMD/SMT |
| Test Current | 5µA |
| Voltage Rating (DC) | 140V |
| Width | 3.95mm |
