| Breakdown Voltage | 200V |
| Capacitance | 60pF |
| Case/Package | SMD/SMT |
| China RoHS | Non-Compliant |
| Clamping Voltage | 265V |
| Country of Origin | Mainland China |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Height | 2.45mm |
| Hold Current | 150mA |
| Harmonized Tariff Schedule (HTS) Code | 8541.30.00.80 |
| Introduction Date | 1980-01-04 |
| Lead Free | Lead Free |
| Leakage Current | 2µA |
| Length | 4.6mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 200V |
| Max Operating Temperature | 150°C |
| Max Repetitive Reverse Voltage (Vrrm) | 200V |
| Max Reverse Leakage Current | 2µA |
| Max Surge Current | 100A |
| Min Breakdown Voltage | 200V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 180V |
| Packaging | Cut Tape |
| Peak Pulse Current | 100A |
| Polarity | Bidirectional |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 180V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Test Current | 5µA |
| Voltage Rating (DC) | 200V |
| Width | 3.95mm |
Farnell
Farnell
Arrow Electronics
Verical
DigiKey
DigiKey
DigiKey
Mouser
TME
Avnet
Diodes Inc.
|
Production
|
Littelfuse
|
Production
|
Diodes Inc.
|
Production
|
Littelfuse
|
Obsolete
|
Teccor
|
Obsolete
|
