| Breakdown Voltage | 51V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 70.1V |
| Country of Origin | Mainland China, Taiwan |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 1V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 7Ω |
| Introduction Date | 2021-03-09 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 53.6V |
| Max Forward Surge Current (Ifsm) | 2.5A |
| Max Junction Temperature (Tj) | 175°C |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 3W |
| Max Repetitive Reverse Voltage (Vrrm) | 250V |
| Max Reverse Leakage Current | 1µA |
| Min Breakdown Voltage | 48.5V |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Peak Pulse Current | 21.4A |
| Peak Pulse Power | 1.5kW |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Dissipation | 3W |
| REACH SVHC | No |
| Reference Voltage | 13V |
| Reverse Recovery Time | 50ns |
| Reverse Standoff Voltage | 43.6V |
| RoHS | Compliant |
| Test Current | 28.8mA |
| Voltage Tolerance | 5% |
| Zener Current | 28.8mA |
| Zener Voltage | 13V |
