| Breakdown Voltage | 56V |
| Case/Package | DO-15 |
| China RoHS | Non-Compliant |
| Clamping Voltage | 77V |
| Country of Origin | Mainland China |
| Diameter | 3.56mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 1V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 1991-08-15 |
| Lead Free | Lead Free |
| Length | 7.62mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 58.8V |
| Max Forward Surge Current (Ifsm) | 2.5A |
| Max Junction Temperature (Tj) | 175°C |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Repetitive Reverse Voltage (Vrrm) | 250V |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 100A |
| Min Breakdown Voltage | 53.2V |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 47.8V |
| Peak Pulse Current | 8.1A |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Power Dissipation | 200mW |
| Power Rating | 600W |
| REACH SVHC | No |
| Reverse Recovery Time | 50ns |
| Reverse Standoff Voltage | 47.8V |
| RoHS | Compliant |
| Voltage Rating (DC) | 56V |
