| Breakdown Voltage | 6.8V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 10.5V |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 1V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 1998-06-18 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 7.14V |
| Max Forward Surge Current (Ifsm) | 2.5A |
| Max Junction Temperature (Tj) | 175°C |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Repetitive Reverse Voltage (Vrrm) | 250V |
| Max Reverse Leakage Current | 1mA |
| Min Breakdown Voltage | 6.45V |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Peak Pulse Current | 57.1A |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Power Dissipation | 200mW |
| REACH SVHC | No |
| Reverse Recovery Time | 50ns |
| Reverse Standoff Voltage | 5.8V |
| RoHS | Compliant |
| Schedule B | 8541100080, 8541100080|8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
