| China RoHS |
Non-Compliant |
| Contact Plating |
Tin |
| Country of Origin |
Mainland China, Taiwan |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Element Configuration |
Single |
| Forward Current |
2A |
| Forward Voltage |
1.3V |
| Height |
2.61mm |
| Harmonized Tariff Schedule (HTS) Code |
8541.10.00.80 |
| Introduction Date |
1998-08-01 |
| Length |
4.75mm |
| Lifecycle Status |
Production |
| Manufacturer Lifecycle Status |
ACTIVE |
| Max Forward Surge Current (Ifsm) |
50A |
| Max Junction Temperature (Tj) |
150°C |
| Max Operating Temperature |
150°C |
| Max Output Current |
2A |
| Max Repetitive Reverse Voltage (Vrrm) |
1kV |
| Max Reverse Leakage Current |
5µA |
| Max Surge Current |
50A |
| Min Operating Temperature |
-55°C |
| Mount |
Surface Mount |
| Number of Elements |
1 |
| Number of Pins |
2 |
| Number of Terminals |
2 |
| Packaging |
Cut Tape |
| Peak Reverse Current |
5µA |
| Power Dissipation |
400mW |
| REACH SVHC |
No |
| Recovery Time |
500ns |
| Reverse Recovery Time |
500ns |
| Reverse Standoff Voltage |
1kV |
| Reverse Voltage |
1kV |
| RoHS |
Compliant |
| Schedule B |
8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
| Width |
3.73mm |
