| Approvals |
CSA |
| China RoHS |
Non-Compliant |
| Connector Type |
Header, Pin, Plug |
| Contact Current Rating |
3A |
| Contact Finish Thickness - Mating |
381nm |
| Contact Gender |
Male |
| Contact Plating |
Gold |
| Contact Shape |
Square |
| Contact Style |
Pin |
| Current Rating |
3A |
| Dielectric Material |
Polyethylene |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| ELV |
Non-Compliant |
| Flammability Rating |
UL94 V-0 |
| Housing Color |
Black |
| Housing Material |
Thermoplastic |
| Harmonized Tariff Schedule (HTS) Code |
8536.69.40.40 |
| Insulation Resistance |
5GΩ |
| Introduction Date |
1995-12-18 |
| Lead Length |
18.77mm |
| Lifecycle Status |
Obsolete |
| Mating Post Length |
8.38mm |
| Max Operating Temperature |
125°C |
| Min Operating Temperature |
-65°C |
| Mount |
Through Hole |
| Number of Contacts |
8 |
| Number of Pins |
8 |
| Number of Ports |
1 |
| Number of Positions |
8 |
| Number of Rows |
2 |
| Orientation |
Vertical |
| Packaging |
Carton |
| PCB Mounting Orientation |
Vertical |
| PCB Mount Retention |
Without |
| Pitch |
2.54mm |
| Plating |
Gold |
| Plating Thickness |
381nm |
| Radiation Hardening |
No |
| REACH SVHC |
No |
| RoHS |
Non-Compliant |
| Row Spacing |
2.54mm |
| Shielding |
Unshielded |
| Stackable |
Yes |
| Stack Height |
7.62mm |
| Tail Length |
2.77mm |
| Terminal Pitch |
2.54mm |
| Termination |
Through Hole |
