| Approvals | CSA |
| China RoHS | Compliant |
| Color | Black |
| Connector Type | Header, Pin, Plug |
| Contact Current Rating | 3A |
| Contact Gender | Male |
| Contact Material | Bronze |
| Contact Mating Length | 8.0772mm |
| Contact Plating | Tin |
| Contact Shape | Square |
| Contact Style | Pin |
| Current Rating | 3A |
| Depth | 4.88mm |
| Dielectric Material | Polyethylene |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| High Speed Serial Data Connector | No |
| High Temperature Housing | Yes |
| Housing Color | Black |
| Housing Material | Thermoplastic |
| Insulation Resistance | 5GΩ |
| Keyed | No |
| Lead Free | Lead Free |
| Lead Length | 3.175mm |
| Length | 9.75mm |
| Lifecycle Status | Production |
| Mating Post Length | 8.08mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Contacts | 8 |
| Number of Pins | 8 |
| Number of Ports | 1 |
| Number of Positions | 8 |
| Number of Rows | 2 |
| Operating Supply Voltage | 30V |
| Orientation | Vertical |
| PCB Mounting Orientation | Vertical |
| PCB Thickness | 1.5748mm |
| Pitch | 2.54mm |
| Plating Thickness | 5.08µm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 2.794mm |
| Shielding | Unshielded |
| Terminal Pitch | 2.54mm |
| Termination | Through Hole |
