| Body Material | Brass |
| Body Plating | Nickel |
| Case/Package | SMA |
| China RoHS | Non-Compliant |
| Connector Type | Plug |
| Contact Gender | Male |
| Contact Material | Brass |
| Contact Resistance | 10mΩ |
| Depth | 21.16mm |
| Dielectric Material | PTFE |
| ELV | Compliant |
| Fastening Type | Threaded |
| Frequency | 26GHz |
| Gender | Male |
| Impedance | 50Ω |
| Insertion Loss (dB) | 0.06dB |
| Insulation Resistance | 5GΩ |
| Lead Free | Lead Free |
| Length | 24.9174mm |
| Lifecycle Status | Obsolete |
| Max Frequency | 12.4GHz |
| Max Operating Temperature | 165°C |
| Min Operating Temperature | -65°C |
| Mount | Cable, Free Hanging |
| Number of Contacts | 1 |
| Number of Pins | 1 |
| Number of Ports | 1 |
| Number of Positions | 1 |
| Orientation | Straight |
| Outside Diameter | 6.35mm |
| Packaging | Carton |
| PCB Mounting Orientation | Straight |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | No |
| Shell Finish | Nickel |
| Shell Material | Brass |
| Shielding | Unshielded |
| Termination | Crimp |
