| Case/Package | PDIP |
| Direction | Unidirectional |
| Height | 5.08mm |
| Lead Free | Lead Free |
| Length | 19.3mm |
| Lifecycle Status | Production |
| Logic Function | Shift Register |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Number of Bits per Element | 8 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Input Lines | 1 |
| Number of Output Lines | 9 |
| Number of Pins | 16 |
| Operating Supply Voltage | 5V |
| Packaging | Rail/Tube |
| Propagation Delay | 10.2ns |
| RoHS | Compliant |
| Thickness | 3.9mm |
| Turn-On Delay Time | 12ns |
| Weight | 951.693491mg |
| Width | 6.35mm |
Texas Instruments
|
Production
|
Nexperia
|
Production
|
Nexperia
|
Production
|
Nexperia
|
Production
|
Fairchild Semiconductor
|
Obsolete
|
