| Case/Package | SOT-23 |
| China RoHS | Compliant |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Anode |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 80Ω |
| Introduction Date | 2013-05-08 |
| Lifecycle Status | Production |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 300mW |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 2 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Polarity | Unidirectional |
| Power Dissipation | 300mW |
| REACH SVHC | Yes |
| Reference Voltage | 33V |
| RoHS | Compliant |
| Tolerance | 5% |
| Voltage Tolerance | 5% |
| Weight | 8.788352mg |
| Zener Current | 5mA |
| Zener Voltage | 33V |
Taiwan Semiconductor
|
Production
|
Diodes Inc.
|
Obsolete
|
Panjit
|
Production
|
Vishay
|
Obsolete
|
Taiwan Semiconductor
|
Production
|
