| Case/Package | SOT-23-3 |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Impedance | 10Ω |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 300mW |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 2 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Peak Reverse Current | 3µA |
| Polarity | Unidirectional |
| Power Dissipation | 300mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reference Voltage | 6.2V |
| Reverse Standoff Voltage | 4V |
| RoHS | Compliant |
| Test Current | 5mA |
| Tolerance | 5% |
| Voltage Tolerance | 5% |
| Weight | 8.788352mg |
| Working Voltage | 6.2V |
| Zener Current | 5mA |
| Zener Voltage | 6.2V |
