| Breakdown Voltage | 4.6V |
| Capacitance | 420pF |
| Case/Package | SOT-23-3 |
| China RoHS | Compliant |
| Clamping Voltage | 10V |
| Composition | Zener |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-03-18 |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 150°C |
| Min Breakdown Voltage | 4V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Elements | 2 |
| Number of Terminals | 3 |
| Number of Unidirectional Channels | 2 |
| Peak Pulse Current | 30A |
| Peak Pulse Power | 369W |
| Polarity | Bidirectional, Unidirectional |
| Power Line Protection | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 3.3V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Weight | 8.788352mg |
