| Average Rectified Current | 7.5A |
| Case/Package | TO-220AB |
| Current Rating | 15A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Cathode |
| Forward Current | 15A |
| Forward Voltage | 840mV |
| Height | 8.24mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.80 |
| Introduction Date | 2002-07-31 |
| Length | 10.5mm |
| Lifecycle Status | Production |
| Max Forward Surge Current (Ifsm) | 150A |
| Max Operating Temperature | 150°C |
| Max Output Current | 7.5A |
| Max Repetitive Reverse Voltage (Vrrm) | 45V |
| Max Reverse Leakage Current | 100µA |
| Max Reverse Voltage (DC) | 45V |
| Max Surge Current | 690A |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Elements | 2 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Packaging | Bulk |
| Peak Non-Repetitive Surge Current | 690A |
| Peak Reverse Current | 100µA |
| REACH SVHC | No |
| Reverse Standoff Voltage | 45V |
| RoHS | Non-Compliant |
| Voltage Rating (DC) | 45V |
| Width | 4.7mm |
