| Breakdown Voltage | 400V |
| Capacitance | 400pF |
| China RoHS | Non-Compliant |
| Clamping Voltage | 548V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 420V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Surge Current | 100A |
| Min Breakdown Voltage | 380V |
| Min Operating Temperature | -55°C |
| Mount | Reverse |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 342V |
| Packaging | Cut Tape |
| Peak Pulse Current | 1.1A |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Reverse Standoff Voltage | 342V |
| RoHS | Compliant |
