| Breakdown Voltage | 30V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 41.4V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2019-02-07 |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 31.5V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 5W |
| Min Breakdown Voltage | 28.5V |
| Min Operating Temperature | -65°C |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Peak Pulse Power | 600W |
| Peak Reverse Current | 1µA |
| Polarity | Bidirectional |
| Reverse Standoff Voltage | 25.6V |
| RoHS | Compliant |
