| Average Rectified Current | 3A |
| China RoHS | Non-Compliant |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Forward Voltage | 1.3V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.80 |
| Introduction Date | 2006-09-06 |
| Lifecycle Status | NRND |
| Max Forward Surge Current (Ifsm) | 125A |
| Max Operating Temperature | 175°C |
| Max Output Current | 3A |
| Max Repetitive Reverse Voltage (Vrrm) | 600V |
| Max Reverse Leakage Current | 5µA |
| Max Reverse Voltage (DC) | 600V |
| Max Surge Current | 125A |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Peak Non-Repetitive Surge Current | 125A |
| Peak Reverse Current | 5µA |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Recovery Time | 250ns |
| Reverse Recovery Time | 250ns |
| Reverse Standoff Voltage | 600V |
| RoHS | Compliant |
