| Breakdown Voltage | 11.1V |
| Capacitance | 570pF |
| China RoHS | Non-Compliant |
| Clamping Voltage | 17V |
| Depth | 1.9mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-10-07 |
| Lead Free | Lead Free |
| Leakage Current | 2.5µA |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 11.1V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 200W |
| Min Breakdown Voltage | 11.1V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 10V |
| Peak Pulse Current | 11.8A |
| Peak Pulse Power | 1kW |
| Polarity | Unidirectional |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Breakdown Voltage | 11.1V |
| Reverse Standoff Voltage | 10V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Working Voltage | 10V |
