| Breakdown Voltage | 16.45V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 23.2V |
| Composition | Zener |
| Country of Origin | Mainland China |
| Depth | 1.9mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Forward Voltage | 2.5V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-11-19 |
| Leakage Current | 100nA |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 17.3V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 200W |
| Min Breakdown Voltage | 15.6V |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 14V |
| Packaging | Tape & Reel (TR) |
| Peak Pulse Current | 8.6A |
| Peak Pulse Power | 200W |
| Peak Reverse Current | 100nA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 14V |
| RoHS | Compliant |
| Schedule B | 8536300000 |
| Termination | SMD/SMT |
| Working Voltage | 14V |
