| Breakdown Voltage | 18.75V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 26V |
| Composition | Zener |
| Depth | 1.9mm |
| Direction | Unidirectional |
| Element Configuration | Single |
| Forward Voltage | 2.5V |
| Leakage Current | 100nA |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 19.7V |
| Max Operating Temperature | 150°C |
| Min Breakdown Voltage | 17.8V |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Packaging | Tape & Reel (TR) |
| Peak Pulse Current | 7.7A |
| Peak Pulse Power | 200W |
| Peak Reverse Current | 100nA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 16V |
| RoHS | Compliant |
| Working Voltage | 16V |
