| Case/Package | PLCC |
| China RoHS | Compliant |
| Color | Green |
| Dominant Wavelength | 568.5nm |
| Forward Current | 30mA |
| Forward Voltage | 2.8V |
| Height | 1.75mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Green |
| Introduction Date | 2006-07-13 |
| Length | 3mm |
| Lens Style | Circular, Clear, Diffused |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 12.55mcd |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Tape & Reel (TR) |
| Peak Wavelength | 565nm |
| Power Rating | 100mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Voltage | 6V |
| RoHS | Compliant |
| Shape | Round |
| Terminal Pitch | 2.8mm |
| Test Current | 10mA |
| Viewing Angle | 120° |
| Wavelength | 575nm |
| Width | 2.8mm |
