| Body Material | Glass |
| Diameter | 2.6mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 130Ω |
| Introduction Date | 2002-05-20 |
| Length | 5.2mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 1W |
| Max Reverse Leakage Current | 500nA |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Polarity | Unidirectional |
| Power Dissipation | 1W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reference Voltage | 68V |
| RoHS | Compliant |
| Test Current | 10mA |
| Tolerance | 5% |
| Voltage Tolerance | 5.88% |
| Zener Current | 10mA |
| Zener Voltage | 68V |
