| Actuator Length | 300µm |
| Actuator Material | Liquid Crystal Polymer, Polymer |
| Contact Current Rating | 20mA |
| Contact Material | Stainless Steel, Steel |
| Contact Plating | Silver |
| Contact Resistance | 100mΩ |
| Current Rating | 20mA |
| Height | 1.5mm |
| Illumination Type | Illuminated, Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Length | 5mm |
| Max Operating Temperature | 85°C |
| Mechanical Life | 200kcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Packaging | Tape and Reel |
| REACH SVHC | No |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 250µm |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating | 15V |
| Width | 5mm |
