0603ZC224KAT2A - Kyocera AVX
AVX - 0603ZC224KAT2A - SMD Multilayer Ceramic Capacitor, 0.22 µF, 10 V, 0603 [1608 Metric], ± 10%, X7R, AVX 0603 MLCC
Technical Details
| Capacitance | 220nF |
| Case Code (Imperial) | 0603 |
| Case Code (Metric) | 1608 |
| Case/Package | 0603 |
| Construction | Flat |
| Depth | 0.81mm |
| Dielectric | X7R |
| Dissipation Factor | 5% |
| Height | 0.9mm |
| Insulation Resistance | 100GR |
| Lead Free | Lead Free |
| Length | 1.6mm |
| Material | Ceramic |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount, PCB |
| Number of Pins | 2 |
| Package Quantity | 4000 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
| Thickness | 0.034inch |
| Tolerance | 10% |
| Voltage | 10V |
| Voltage Rating | 10V |
| Voltage Rating (AC) | 10V |
| Voltage Rating (DC) | 10V |
| Width | 0.81mm |
Compliance
RoHS : Compliant
Images
Future Electronics
Future Electronics
Rs
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| TDK | Obsolete | ||
| Murata | Volume Production | ||
| Johanson | Volume Production | ||
| Yageo | Volume Production | ||
| KEMET | Volume Production | ||
| Murata | Not Recommended for New Design | ||
| Murata | Volume Production | ||
| KEMET | Volume Production | ||
| KEMET | Volume Production | ||
| KEMET | Volume Production |
