39-01-2100 - Molex

MOLEX 39-01-2100.. RECEPTACLE, MINI-FIT, 10WAY

Technical Details

Approvals	UL, CSA, TUV
Body Material	Nylon, Polyamide
Color	Natural
Connector Type	Receptacle
Contact Gender	Female
Contact Resistance	10mR
Contact Type	Female Socket
Current Rating	13A
Depth	19.6mm
Fastening Type	Latch
Flammability Rating	UL94 V-0
Gender	Receptacle
Glow Wire Compliant	Non-compliant
Halogen Free	Low Halogen
Height	14.1mm
Housing Color	Natural
Housing Material	Nylon
Lead Free	Lead Free
Length	22.2mm
Material	Nylon
Max Operating Temperature	105°C
Min Operating Temperature	-40°C
Max Voltage Rating (AC)	600V
Max Voltage Rating (DC)	600V
Number of Contacts	10
Number of Positions	10
Number of Rows	2
Orientation	Straight
Package Quantity	2500
Packaging	Bulk
Pitch	4.2mm
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Row Spacing	0.165inch
Series	Mini-Fit® Jr™ 5557
Termination	Crimp
Voltage Rating	600V
Voltage Rating (AC)	250V
Width	15.1mm
Working Voltage	250V

Compliance

RoHS : Compliant

Radiation Hardening : No

Images

Molex 39-01-2100 | Mouser

Mouser

Molex 39-01-2100 | Element14

Element14

Molex 39-01-2100 | Distrelec

Distrelec

Molex 39-01-2100 | Verical

Verical

Molex 39-01-2100 | Arrow Electronics

Arrow Electronics

Molex 39-01-2100 | Rs

Rs

Datasheets

Mouser

39-01-2100 datasheet (pdf, 35.5 KB)

Onlinecomponents.com

39-01-2100 datasheet (pdf, 36 KB)

Element14

39-01-2100 datasheet (pdf, 36 KB)

Lifecycle Status Indicator

Volume Production

Loading indicators

Symbol

39-01-2100 Symbol - Molex
