ADM232AANZ - Analog Devices
ANALOG DEVICES ADM232AANZ RS232 Transceiver, 2-drivers, 4.5V-5.5V Supply, DIP-16
Technical Details
| Case/Package | PDIP |
| Contact Plating | Tin, Matte |
| Data Rate | 200Kbps |
| ESD Protection | No |
| Height | 3.3mm |
| Interface | RS-232 |
| Lead Free | Contains Lead |
| Length | 20.07mm |
| Logic Function | Transceiver, Receiver |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Current | 8mA |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Drivers | 2 |
| Number of Pins | 16 |
| Number of Receivers | 2 |
| Number of Transceivers | 1 |
| Number of Transmitters | 2 |
| Operating Supply Current | 8mA |
| Operating Supply Voltage | 5V |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Receiver Hysteresis | 400mV |
| RoHS Compliant | Yes |
| Simplex/Duplex | Full Duplex |
| Supply Current | 8mA |
| Width | 6.35mm |
Compliance
Images
Mouser
Rs
Jameco
Newark
Distrelec
Farnell
Element14
Today Components
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Analog Devices | Volume Production | ||
| Intersil | Volume Production | ||
| Maxim | Volume Production | ||
| Maxim | Not Recommended for New Design | ||
| Texas Instruments | Volume Production | ||
| STMicroelectronics | Volume Production | ||
| Exar | Volume Production | ||
| Analog Devices | Volume Production | ||
| Texas Instruments | End of Life | ||
| Texas Instruments | Obsolete |
