MAX5490GC01000+T - Analog Devices
Resistor Networks & Arrays 100kohm Precision-Matched Resistor-Divider in SOT23
Technical Details
| Case/Package | SOT-23-3 |
| Circuit Type | Voltage Divider |
| Height | 1.1176mm |
| Length | 2.921mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Number of Elements | 2 |
| Number of Pins | 3 |
| Number of Resistors | 2 |
| Power Per Element | 67.2mW |
| Power Rating | 67.2mW |
| Radiation Hardening | No |
| REACH SVHC | No |
| Resistance | 100kΩ |
| RoHS | Compliant |
| Temperature Coefficient | 35ppm/°C |
| Termination | SMD/SMT |
| Tolerance | 0.1% |
| Voltage Rating | 100V |
| Voltage Rating (DC) | 80V |
| Width | 1.2954mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
