ALS31A153DB040 - BHC Components
Capacitor, 15000UF 40V Capacitor, 15000UF 40V; Capacitance: 15000UF; Voltage Rating, DC: 40V; Capacitor Dielectric...
Technical Details
| Capacitance | 15mF |
| Case/Package | Radial |
| Diameter | 36mm |
| Dielectric Material | Aluminium |
| ESR (Equivalent Series Resistance) | 17mΩ |
| Height | 62mm |
| Lead Diameter | 8mm |
| Lead Length | 7.14mm |
| Lead Pitch | 12.7mm |
| Leakage Current | 360µA |
| Length | 62mm |
| Life (Hours) | 11000hours |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Number of Pins | 3 |
| REACH SVHC | No |
| Ripple Current | 9.5A |
| Ripple Current (AC) | 9.5A |
| RoHS | Compliant |
| Termination | Screw, Stud |
| Thread Size | M8 |
| Tolerance | 20% |
| Voltage | 40V |
| Voltage Rating | 40V |
| Voltage Rating (DC) | 40V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
