Technical Details
| Body Material | Nylon, Polyamide |
| Breakdown Voltage | 3.5kV |
| Color | White |
| Connector Type | Plug |
| Contact Material | Brass |
| Contact Plating | Nickel |
| Current Rating | 10A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gender | Male |
| Insulation | Non-Mating End Insulated |
| Insulation Material | Nylon |
| Introduction Date | 1998-03-26 |
| Lead Free | Lead Free |
| Length | 34.52mm |
| Lifecycle Status | Production |
| Max Current Rating | 10A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Cable, Free Hanging |
| Number of Contacts | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Solder |
| Voltage Rating | 1.75kV |
| Voltage Rating (DC) | 3.5kV |
| Wire/Cable Gauge | 16AWG |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Master Electronics
Authorized Distributors
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Fly-Wing Technology |
HK: 415
|
$ | 1.5312 | 1.335 | 1.335 | 1.2785 | 1.1931 | 1.1931 | ||
| Freelance Electronics |
US: 10
|
$ | 0.59 | 0.59 | 0.59 | 0.59 | 0.59 | 0.59 | ||
