Technical Details
| Body Material | Nylon, Polyamide |
| Breakdown Voltage | 3.5kV |
| Color | Green |
| Contact Material | Brass, Copper |
| Contact Plating | Silver |
| Current Rating | 5A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gender | Female |
| Insulation | Mating End Insulated |
| Insulation Material | Nylon |
| Introduction Date | 1995-01-01 |
| Lead Free | Lead Free |
| Length | 17.78mm |
| Lifecycle Status | Production |
| Max Current Rating | 5A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Contacts | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Solder, Turret |
| Voltage Rating | 1.75kV |
| Voltage Rating (DC) | 3.5kV |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
