Technical Details
| Actuator Color | Red |
| Actuator Length | 7mm |
| Actuator Type | Round, Button |
| Color | Red |
| Contact Current Rating | 100mA |
| Contact Plating | Silver |
| Contact Resistance | 100mR |
| Current Rating | 100mA |
| Diameter | 12mm |
| Electrical Life | 250000Cycles |
| Height | 14.3mm |
| Illumination Type | Illuminated |
| Insulation Resistance | 100GR |
| Lead Free | Lead Free |
| Lead Pitch | 5mm |
| Max Current Rating | 100mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -20°C |
| Max Voltage Rating (DC) | 32V |
| Mount | Through Hole |
| Number of Pins | 4 |
| Number of Positions | 2 |
| Operating Force | 1.3N |
| Orientation | Straight |
| Outside Diameter | 12mm |
| Package Quantity | 1000 |
| Packaging | Tray |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Row Spacing | 5mm |
| Series | D6 |
| Switch Function | Off-Mom |
| Terminal Pitch | 5mm |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 32V |
| Width | 11.4mm |
Compliance
RoHS : Not Compliant
