BGB707L7ESDE6327XTSA1 - Infineon
RF Amplifier, AEC-Q101, 150MHz to 10GHz, 27dB Gain, 0.4dB Noise, 1.8V to 4V, TSLP-7
Technical Details
| China RoHS | Compliant |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gain | 27dB |
| Halogen Free | Halogen Free |
| Height | 500µm |
| Height - Seated (Max) | 500µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.33.00.01 |
| Introduction Date | 2008-12-10 |
| Lead Free | Lead Free |
| Length | 2mm |
| Lifecycle Status | Production |
| Max Frequency | 10GHz |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 100mW |
| Max Supply Voltage | 4V |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Noise Figure | 0.4dB |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Pins | 6 |
| Number of Terminals | 7 |
| Operating Supply Voltage | 3V |
| P1dB | 6dBm |
| Package Quantity | 7500 |
| Packaging | Tape & Reel |
| Power Dissipation | 100mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Terminal Pitch | 500µm |
| Width | 1.3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
