S29GL128S90FHI010 - Infineon
IC FLASH 128MBIT PARALLEL 64FBGA FLASH - NOR Memory IC 128Mbit Parallel 90 ns 64-FBGA (13x11)
Technical Details
| Access Time | 90ns |
| Address Bus Width | 23b |
| Case/Package | FBGA |
| China RoHS | Compliant |
| Density | 128Mb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.4mm |
| Height - Seated (Max) | 1.4mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.51 |
| Interface | Parallel |
| Introduction Date | 2020-04-14 |
| Length | 13mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Supply Current | 80mA |
| Max Supply Voltage | 3.6V |
| Memory Size | 128MB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Nominal Supply Current | 60mA |
| Number of Circuits | 1 |
| Number of Pins | 64 |
| Number of Terminals | 64 |
| Operating Supply Voltage | 3V |
| Page Size | 32B |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sync/Async | Asynchronous |
| Temperature Grade | Industrial |
| Terminal Pitch | 1mm |
| Width | 11mm |
| Word Size | 16b |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
