C0603C391J5GACTU - KEMET
Multilayer Ceramic Capacitors MLCC - SMD/SMT 50V 390pF C0G 0603 5%
Technical Details
| Capacitance | 390pF |
| Case/Package | 0603 |
| Case Code (Imperial) | 0603 |
| China RoHS | Compliant |
| Country of Origin | Mexico |
| Depth | 800µm |
| Dielectric | C0G |
| Dielectric Material | Ceramic |
| Dissipation Factor | 0.1% |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 800µm |
| Harmonized Tariff Schedule (HTS) Code | 8532.24.00.20 |
| Introduction Date | 2008-06-06 |
| Lead Free | Lead Free |
| Lead Pitch | 700µm |
| Length | 1.6mm |
| Lifecycle Status | Production |
| Material | Ceramic |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8532240020, 8532240020|8532240020, 8532240020|8532240020|8532240020, 8532240020|8532240020|8532240020|8532240020 |
| Temperature Coefficient | 30ppm/°C |
| Termination | SMD/SMT |
| Thickness | 863.6µm |
| Tolerance | 5% |
| Voltage | 50V |
| Voltage Rating | 50V |
| Voltage Rating (AC) | 50V |
| Voltage Rating (DC) | 50V |
| Width | 800µm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
