LPV-60-12 - Mean Well
Power Supply, 60W Single Output Switching, 12VDC, 5A, 120VP-P Ripple, 47-63HZ, 300VAC, IP67
Technical Details
| Approvals | CB, CE, CSA, EN, IEC, UL |
| Current - Output 1 | 5A |
| Current Rating | 5A |
| Depth | 42.5mm |
| Efficiency | 83% |
| Height | 32mm |
| Height - Seated (Max) | 32mm |
| Lead Free | Lead Free |
| Length | 162.5mm |
| Lifecycle Status | Production |
| Max Input Current | 1.2A |
| Max Input Voltage | 264V |
| Max Operating Temperature | 70°C |
| Max Output Current | 5A |
| Max Output Power | 60W |
| Max Output Voltage | 12.6V |
| Max Supply Voltage | 370V |
| Min Input Voltage | 90V |
| Min Operating Temperature | -30°C |
| Min Output Voltage | 11.4V |
| Min Supply Voltage | 90V |
| Mount | Panel, Screw |
| Nominal Input Voltage | 115V |
| Nominal Output Voltage | 12V |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 4 |
| Output Current | 5A |
| Output Power | 60W |
| Output Voltage | 12V |
| Power Rating | 60W |
| Radiation Hardening | No |
| Ratings | IP67 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8504409520 |
| Switching Frequency | 65kHz |
| Termination | Cable |
| Topology | Flyback |
| Voltage - Output 1 | 12V |
| Voltage Rating | 264V |
| Weight | 400.000006g |
| Width | 42.5mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
