73412-0110 - Molex
Conn Micro Coaxial RCP 0Hz to 6GHz 50Ohm Solder ST SMD Gold Embossed T/R
Technical Details
| Body Material | Liquid Crystal Polymer, Polymer |
| Body Plating | Gold |
| China RoHS | Compliant |
| Connector Type | Coaxial |
| Contact Gender | Female |
| Contact Material | Brass |
| Contact Plating | Gold |
| Contact Resistance | 25mΩ |
| Country of Origin | US |
| Dielectric Material | Liquid Crystal Polymer |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 6GHz |
| Gender | Female |
| Halogen Free | Low Halogen |
| Height | 1.25mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.10 |
| Impedance | 50Ω |
| Insulation Resistance | 100MΩ |
| Introduction Date | 2007-05-08 |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Material | Bronze |
| Max Frequency | 6GHz |
| Max Operating Temperature | 90°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Pins | 1 |
| Number of Ports | 1 |
| Orientation | Straight |
| Packaging | Tape and Reel |
| Polarity | Standard |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Solder |
| Voltage Rating | 60V |
| Voltage Rating (AC) | 60V |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
