DLW31SN102SQ2L - Murata
DLW Series 1206 1000 Ohm 230 mA 1 Ohm DCR 50 V SMT Common Mode Choke
Technical Details
| Case/Package | 3216 |
| Case Code (Imperial) | 1206 |
| Composition | Wirewound |
| Contact Plating | Tin |
| Country of Origin | Japan |
| Current | 230mA |
| Current Rating | 230mA |
| DC Current | 230mA |
| DC Resistance (DCR) | 1Ω |
| Depth | 1.6mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 100MHz |
| Height | 1.9mm |
| Harmonized Tariff Schedule (HTS) Code | 8504.50.80.00 |
| Impedance | 1kΩ |
| Insulation Resistance | 10MΩ |
| Introduction Date | 2001-06-01 |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lifecycle Status | Production |
| Max DC Current | 230mA |
| Max Operating Temperature | 85°C |
| Military Standard | Not |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 2 |
| Number of Lines | 2 |
| Number of Pins | 4 |
| Number of Terminals | 4 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RMS Current (Irms) | 230mA |
| RoHS | Compliant |
| Schedule B | 8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000 |
| Self Resonant Frequency | 100MHz |
| Series Resistance | 1Ω |
| Shielding | Unshielded |
| Termination | SMD/SMT |
| Test Frequency | 100MHz |
| Tolerance | 25% |
| Voltage Rating | 50V |
| Voltage Rating (DC) | 125V |
| Weight | 39.008944mg |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
