Technical Details
| Breakdown Voltage | 12.4V |
| Case/Package | Axial |
| Clamping Voltage | 18.2V |
| Clamping Voltage-Max | 18.2V |
| Diode Type | ZENER |
| Direction | Unidirectional |
| ESD Protection | Yes |
| Height | 3.68mm |
| Lead Free | Lead Free |
| Leakage Current | 5uA |
| Length | 8.89mm |
| Max Breakdown Voltage | 13.7V |
| Min Breakdown Voltage | 12.4V |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Reverse Leakage Current | 5uA |
| Max Surge Current | 33A |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 11.1V |
| Package Quantity | 4000 |
| Packaging | Tape and Reel |
| Peak Pulse Current | 33A |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Power Dissipation | 600W |
| Power Line Protection | No |
| Reverse Breakdown Voltage | 12.4V |
| Reverse Standoff Voltage | 11.1V |
| RoHS Compliant | Yes |
| Termination | Axial |
| Test Current | 1mA |
| Width | 3.68mm |
Compliance
RoHS : Compliant
Images
Rochester Electronics
Mouser
Arrow Electronics
Digikey
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Diodes | Volume Production | ||
| STMicroelectronics | Volume Production | ||
| onsemi | End of Life | ||
| onsemi | End of Life | ||
| Littelfuse | Volume Production | ||
| onsemi | Volume Production | ||
| STMicroelectronics | Obsolete | ||
| Vishay Semiconductors | Volume Production | ||
| Vishay Semiconductors | Volume Production | ||
| Vishay Semiconductors | Volume Production |
