EEHZC1E101XP - Panasonic
Conductive Polymer Hybrid Aluminum Electrolytic Capacitors, 100µF, 25V, -55 to 125¡C
Technical Details
| Capacitance | 100µF |
| Case/Package | Radial |
| Country of Origin | Japan, Malaysia |
| Diameter | 6.3mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ESR (Equivalent Series Resistance) | 30mΩ |
| Height | 7.7mm |
| Height - Seated (Max) | 8.001mm |
| Harmonized Tariff Schedule (HTS) Code | 8532.22.00.20 |
| Introduction Date | 2012-01-13 |
| Lead Diameter | 650µm |
| Lead Free | Lead Free |
| Lead Pitch | 1.8mm |
| Leakage Current | 25µA |
| Length | 7.7mm |
| Life (Hours) | 4000hours |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Material | Polymer |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Pins | 8 |
| Number of Terminals | 2 |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Ripple Current | 1.4A |
| Ripple Current (AC) | 1.4A |
| RoHS | Compliant |
| Schedule B | 8532220020 |
| Part Series | ZC (High temp. reflow) |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage | 25V |
| Voltage Rating | 25V |
| Voltage Rating (DC) | 25V |
| Width | 6.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
