EXB-18VR000X - Panasonic
Res Thick Film Array 0 Ohm ISOL Molded 8-Pin 0502(4 X 0201) Flat SMD Punched Carrier T/R
Technical Details
| Case/Package | 0502 |
| Case Code (Imperial) | 0502 |
| Case Code (Metric) | 1106 |
| Circuit Type | Isolated |
| Composition | Thick Film |
| Contact Plating | Tin |
| Country of Origin | Japan |
| Depth | 600µm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 350µm |
| Harmonized Tariff Schedule (HTS) Code | 8533.21.00.20 |
| Introduction Date | 2008-06-25 |
| Lead Free | Lead Free |
| Length | 1.4mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Military Standard | Not |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Circuits | 4 |
| Number of Contacts | 8 |
| Number of Elements | 1 |
| Number of Pins | 8 |
| Number of Resistors | 4 |
| Number of Terminals | 8 |
| Packaging | Cut Tape |
| Power Dissipation | 100mW |
| Power Per Element | 31mW |
| Power Rating | 100mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Resistance | 0Ω |
| RoHS | Compliant |
| Part Series | Chip Resistor Array |
| Temperature Coefficient | 200ppm/°C |
| Terminal Pitch | 400µm |
| Termination | Flat |
| Thickness | 350µm |
| Tolerance | 5% |
| Voltage Rating | 12.5V |
| Width | 600µm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
