EXB-A10P471J - Panasonic
Res Thick Film NET 470 Ohm 5% ±200ppm/C BUS 10-Pin 2512 Concave SMD Automotive T/R
Technical Details
| Case/Package | 2512 |
| Case Code (Imperial) | 2512 |
| Case Code (Metric) | 6432 |
| Circuit Type | Bussed |
| Composition | Thick Film |
| Depth | 3.1mm |
| Height | 650µm |
| Lead Free | Lead Free |
| Length | 6.4mm |
| Max Operating Temperature | 125°C |
| Military Standard | Not |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Contacts | 10 |
| Number of Pins | 10 |
| Number of Resistors | 8 |
| Number of Terminals | 10 |
| Packaging | Cut Tape |
| Power Per Element | 62.5mW |
| Radiation Hardening | No |
| Resistance | 470Ω |
| RoHS | Compliant |
| Temperature Coefficient | 200ppm/°C |
| Terminal Pitch | 1.27mm |
| Termination | Concave |
| Tolerance | 5% |
| Voltage Rating | 50V |
| Weight | 40.511469mg |
| Width | 3.1mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Onlinecomponents.com
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| CTS Components | Production | ||
| KOA Speer | Obsolete | ||
| KOA Speer | Obsolete | ||
| CTS Components | Obsolete | ||
| KOA Speer | Obsolete | ||
| ROHM | Obsolete | ||
| KOA Speer | Obsolete | ||
| Panasonic | Unknown | ||
| CTS Components | Production | ||
| Stackpole Electronics | Obsolete |
