SMCJ58CA-E3/57T - Vishay Semiconductors

TVS DIODE 58V 93.6V DO214AB

Technical Details

Breakdown Voltage 64.4V
Case/Package DO-214AB
Clamping Voltage 93V
Clamping Voltage-Max 93.6V
Contact Plating Tin, Matte
Direction Bidirectional
Element Configuration Single
ESD Protection Yes
Forward Voltage 3.5V
Height 2.42mm
Lead Free Lead Free
Leakage Current 1uA
Length 7.11mm
Max Breakdown Voltage 71.2V
Min Breakdown Voltage 64.4V
Max Forward Surge Current (Ifsm) 200A
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Max Power Dissipation 1.5kW
Max Reverse Leakage Current 1uA
Max Surge Current 16A
Mount Surface Mount
Number of Channels 1
Number of Elements 1
Number of Pins 2
Operating Supply Voltage 58V
Package Quantity 850
Packaging Tape and Reel
Peak Pulse Current 16A
Peak Pulse Power 1.5kW
Polarity Bidirectional
Power Dissipation 1.5kW
Radiation Hardening No
REACH SVHC Unknown
Reverse Breakdown Voltage 64.4V
Reverse Standoff Voltage 58V
RoHS Compliant Yes
Series SMCJ
Termination SMD/SMT
Test Current 1mA
Width 6.22mm

Compliance

   RoHS : Compliant
   Radiation Hardening : No
   REACH SVHC : Unknown

Images

Vishay Semiconductors SMCJ58CA-E3/57T | Arrow Electronics

Arrow Electronics

Vishay Semiconductors SMCJ58CA-E3/57T | Digi-Key

Digi-Key

Vishay Semiconductors SMCJ58CA-E3/57T | Farnell

Farnell

Lifecycle Status Indicator

   Volume Production
 Loading indicators
Symbol
Footprint

Alternatives (Possible Substitutes)

Manufacturer Manufacturer Part No. Lifecycle Status Indicator Confidence
Littelfuse Volume Production
Littelfuse Volume Production
Littelfuse Volume Production
Bourns Volume Production
Bourns Volume Production
Diodes Volume Production
Diodes Volume Production
ON Semiconductor / Fairchild Volume Production
Littelfuse Volume Production
ON Semiconductor / Fairchild Volume Production

See more alternatives See less alternatives
