1-1718643-1 - TE Connectivity
Automotive Connector Housing, MCON 1.2, Receptacle, 2 Ways, AMP MCON 1.2 Series Pin Contacts
Technical Details
| China RoHS | Compliant |
| Circuit Application | Signal |
| Color | Black |
| Connector Type | Receptacle, Socket |
| Contact Current Rating | 25A |
| Contact Gender | Female |
| Country of Origin | Hungary |
| Current Rating | 25A |
| Dielectric Material | Polyamide |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Fastening Type | Latch |
| Gender | Receptacle |
| Height | 14.8082mm |
| Housing Color | Black |
| Housing Material | Polyamide |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Hybrid Connector | No |
| Insulation Material | Polyamide |
| Introduction Date | 2014-01-20 |
| Length | 15mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Material | Polyamide |
| Mating Tab Width | 1.1938mm |
| Max Operating Temperature | 130°C |
| Min Operating Temperature | -40°C |
| Mount | Cable, Free Hanging |
| Number of Contacts | 2 |
| Number of Pins | 2 |
| Number of Ports | 1 |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Pitch | 3.9878mm |
| Polarized | Yes |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Serviceable | Yes |
| Shielding | Unshielded |
| Terminal Pitch | 4mm |
| Termination | Crimp |
| Width | 26.4922mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
