CNY17-4 - Vishay
VISHAY CNY17-4 Transistor Output Optocoupler, 1 Channel, 5 kV, 160 %, 60 mA, DIP, 6 Pins
Technical Details
| Ambient Temperature Range High | 110°C |
| Approvals | VDE |
| Case/Package | DIP |
| China RoHS | Compliant |
| Collector Emitter Breakdown Voltage | 32V |
| Collector Emitter Saturation Voltage | 400mV |
| Collector Emitter Voltage (VCEO) | 70V |
| Current Transfer Ratio | 56% |
| Dark Current | 100nA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fall Time | 15µs |
| Forward Current | 60mA |
| Forward Voltage | 1.5V |
| Height | 5.8mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.80.00 |
| Input Current | 60mA |
| Introduction Date | 1993-01-01 |
| Isolation Voltage | 3750Vrms |
| Lead Free | Lead Free |
| Length | 7.3mm |
| Lifecycle Status | Production |
| Max Collector Current | 100mA |
| Max Input Current | 60mA |
| Max Operating Temperature | 100°C |
| Max Output Voltage | 80kV |
| Max Power Dissipation | 150mW |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 6 |
| Output Current per Channel | 100mA |
| Output Type | Phototransistor |
| Output Voltage | 70V |
| Power Dissipation | 250mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 5V |
| Reverse Voltage | 6V |
| Rise Time | 4.6µs |
| RoHS | Compliant |
| Schedule B | 8541408000, 8541408000|8541408000|8541408000|8541408000|8541408000 |
| Turn-Off Delay Time | 25µs |
| Turn-On Delay Time | 6µs |
| Voltage Rating (DC) | 32V |
| Width | 6.5mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
