ACS710KLATR-10BB-NL-T - Allegro MicroSystems
10 A 120 kHz 1 Channel Bandwidth High-Voltage Isolation Current Sensor -SOIC-16
Technical Details
| Accuracy | 1.8% |
| Ambient Temperature Range High | 125°C |
| Body Material | Plastic |
| Case/Package | SOIC |
| China RoHS | Compliant |
| Height | 2.34mm |
| Introduction Date | 2013-06-17 |
| Length | 10.21mm |
| Lifecycle Status | Production |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Pins | 16 |
| Number of Terminals | 16 |
| Operating Supply Current | 11mA |
| Output Configuration | Analog |
| Packaging | Tape and Reel |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sensing Method | Hall Effect |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
