ACS718KMATR-10B-T - Allegro MicroSystems
ACS718 Series 5 V 10 A 40 kHz 1 Channel Hall Effect Current Sensor - SOIC-16
Technical Details
| Accuracy | 2% |
| Ambient Temperature Range High | 125°C |
| Case/Package | SOIC |
| China RoHS | Compliant |
| Current Rating | 9mA |
| Current Sensing | 10A |
| Frequency | 40kHz |
| Height | 2.65mm |
| Introduction Date | 2015-01-28 |
| Length | 10.3mm |
| Lifecycle Status | Production |
| Linearity | 1% |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 125°C |
| Max Supply Current | 9mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Pins | 16 |
| Number of Terminals | 16 |
| Operating Supply Current | 7mA |
| Packaging | Tape & Reel (TR) |
| Polarity | Bidirectional |
| REACH SVHC | Yes |
| Response Time | 13µs |
| RoHS | Compliant |
| Sensing Method | Hall Effect |
| Sensitivity (mV/A) | 200mV/A |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
