ACS725LLCTR-10AU-T - Allegro MicroSystems
Closed Loop/Open Loop Current Sensor AC/DC Current 3.3V Automotive 8-Pin SOIC N T/R
Technical Details
| Accuracy | 0.9% |
| Ambient Temperature Range High | 150°C |
| Bandwidth | 120kHz |
| Case/Package | SOIC |
| China RoHS | Non-Compliant |
| Coil Resistance | 1.2mΩ |
| Current Sensing | 10A |
| Frequency | 120kHz |
| Height | 1.5mm |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Linearity | 1.5% |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 150°C |
| Max Supply Current | 14mA |
| Max Supply Voltage | 3.6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Current | 10mA |
| Output Configuration | Analog |
| Packaging | Tape & Reel (TR) |
| Polarity | Unidirectional |
| Quiescent Current | 10mA |
| REACH SVHC | Yes |
| Response Time | 4µs |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Sensing Method | Hall Effect |
| Sensitivity (mV/A) | 264mV/A |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
