ACS759ECB-200B-PFF-T - Allegro MicroSystems
Current Sensor Current Sensor AC/DC Current 3.3V 5-Pin Case CB-PFF Tube
Technical Details
| Accuracy | 2% |
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Current Sensing | 200A |
| Frequency | 120kHz |
| Height | 7.1mm |
| Introduction Date | 2012-04-09 |
| Lifecycle Status | Production |
| Linearity | 1% |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 85°C |
| Max Supply Current | 13.5mA |
| Max Supply Voltage | 3.6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Operating Supply Current | 10mA |
| Operating Supply Voltage | 3.3V |
| Output Current | 1mA |
| Polarity | Bidirectional |
| REACH SVHC | Yes |
| Response Time | 4µs |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Sensing Method | Hall Effect |
| Sensitivity (mV/A) | 8.8mV/A |
| Temperature Grade | Industrial |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
